Linux kernel 3.17 getrandom()

October 13th, 2014 No comments
Linux Tux from Wikimedia

Linux Tux

Linus Torvalds has just released the Linux kernel version 3.17. Among other things, it comes with a new system call for random numbers named getrandom() introduced by Theodore Ts’o for the needs of applications such as LibreSSL. This new system call can be used to emulate the getentropy() of OpenBSD. Such random numbers are not algorithmic, and their unpredictability is useful for cryptographic and security applications. More information is available on Linux Weekly News.

Excerpt from the commit in the Git repository of the Linux kernel source:

The getrandom(2) system call was requested by the LibreSSL Portable
developers. It is analoguous to the getentropy(2) system call in
OpenBSD.

The rationale of this system call is to provide resiliance against
file descriptor exhaustion attacks, where the attacker consumes all
available file descriptors, forcing the use of the fallback code where
/dev/[u]random is not available. Since the fallback code is often not
well-tested, it is better to eliminate this potential failure mode
entirely.

The other feature provided by this new system call is the ability to
request randomness from the /dev/urandom entropy pool, but to block
until at least 128 bits of entropy has been accumulated in the
/dev/urandom entropy pool. Historically, the emphasis in the
/dev/urandom development has been to ensure that urandom pool is
initialized as quickly as possible after system boot, and preferably
before the init scripts start execution.

This is because changing /dev/urandom reads to block represents an
interface change that could potentially break userspace which is not
acceptable. In practice, on most x86 desktop and server systems, in
general the entropy pool can be initialized before it is needed (and
in modern kernels, we will printk a warning message if not). However,
on an embedded system, this may not be the case. And so with this new
interface, we can provide the functionality of blocking until the
urandom pool has been initialized. Any userspace program which uses
this new functionality must take care to assure that if it is used
during the boot process, that it will not cause the init scripts or
other portions of the system startup to hang indefinitely.

Notes. LibreSSL is a free version of the Secure Sockets Layer (SSL) and Transport Layer Security (TLS) protocols, forked from OpenSSL cryptographic software library in April 2014 by OpenBSD developers after the Heartbleed security vulnerability in OpenSSL.

Share

Deux petites productions pédagogiques du mois de septembre

October 8th, 2014 No comments

Wigner about level spacing and Wishart

September 26th, 2014 2 comments
Figure IIB1.1 Probability of a level spacing X.

Original picture in Wigner’s proceedings.

Have you ever opened The Oxford Handbook of Random Matrix Theory edited by Akemann, Baik, and Di Francesco? The short foreword by Freeman Dyson is fun. I was intrigued, page 16, by a sentence in chapter 2 (“History – An overview”, by Bohigas and Weidenmüller):

… That search and, as he says (see page 225 of Ref. [Por65]), the ‘accidental’ discovery of the Wishart ensemble of random matrices in an early version of the book by Wilks [Wil62], motivated Wigner to use random matrices.

I already knew Wilks’s book [Wil62], but not [Por65], which turned out to be a book:

Statistical Theories of Spectra: Fluctuations, A Collection of Reprints and Original Papers. With an introductory Review by Charles E. Porter, Brookhaven National Laboratory, New York. Academic Press, 1965.

I’ve bought a used copy of this book. Wigner’s paper is a conference proceedings p. 223-225:

Proceedings of the International Conference on the Neutron Interactions with the Nucleus. Held at Columbia University, New York, September 9-13, 1957. Published by the United States Atomic Energy Commission, Technical Information Service Extension, Oak Ridge, Tennessee.

Talk IIB1. E. P. Wigner, Princeton University. Presented by E. P. Wigner.

Distribution of Neutron Resonance Level Spacing.

Session IIB. Interpretation of Low Energy Neutron Spectroscopy.

Chairman: W. W. Havens, Jr.

The problem of the spacing of levels is neither a terribly important one nor have I solved it. That is really the point which I want to make very definitely. As we go up in the energy scale it is evident that the detailed analyses which we have seen for low energy levels is not possible, and we can only make statistical statements about the properties of the energy levels. Statistical properties refer particularly to two quantities, to wit, the distribution of the widths of energy levels and the spacing of energy levels. As far as the widths of the energy levels is concerned, this is an important problem which has been solved experimentally principally by Hughes, Harvey and the group which was at the time at Brookhaven. The theoretical work, which resulted in a relatively minor correction, was done by Scott, Porter and Thomas. The distribution of widths is rather important, as has been shown by Mr. Dresner, since the use of different distributions can introduce a factor of 3 or more in the determination of the average cross sections. Nothing of similar importance can be said about the spacing except that it is tantalizing not to know what the probability of a certain spacing of the energy levels is.

Now, if we have an average spacing, let us say D, what is the probability of a spacing, X. This question is the one which I have not solved, but perhaps I can tell you something about this which is relatively easy to see. It was pointed out at the Amsterdam conference last year that the probability is 0 at X = 0. This is rather obvious, and follows from the fact that if you have a symmetric matrix, the probability that two energy levels coincide is governed by the requirement that two parameters be 0, rather than that one parameter be 0. This was pointed out by Dr. Von Neuman and myself in an article which everybody has probably forgotten, but it is a very easy thing to show. If I take, for Instance, a two-dimensional matrix then the secular equation reads: $$E =1/2(E_1+ E_2) \pm 1/2\sqrt{(E_1 — E_2)^2 + 4V_{(12)}^2}.$$ The two roots can coincide only if the square root is equal to zero, which requires that both $E_1 – E_2 = 0$ and $V_{(12)} =0$. If you have a third order equation, which is slightly more complicated, that tells you two roots coincide, it again amounts to two equations rather than one equation. As a result, the probability is 0 and, therefore, the probability curve looks something like that in Figure 1. This is of course what is also observed. The only question is how does this look for large spacings, and the answer to this question is what I don’t know.

Dr. Hughes presented a curve which I have not seen, in which he compared an experiment with a curve which I suggested some time ago, a form $Xe^{-X^2/2}$ or something like this. Hughes found reasonably good agreement, but the agreement was good in the region of Small X, and not very good in the region of large X. Agreement in this large X region would not look so bad if the experimental curve were the theoretical curve and the theoretical curve, the experimental curve. Because if you could calculate that there should be four cases with a given spacing and you find only one, then that’s unfortunate, but it is a reasonable statistical deviation. However, if you calculate that there should only be one and find four, that is a much more serious deviation and much less probable statistically.

Let me say only one more word. It is very likely that the curve in Figure 1 is a universal function. in other words, it doesn’t depend on the details of the model with which you are working. There is one particular model in which the probability of the energy levels can be written down exactly. I mentioned this distribution already in Gatlinburg. It is called the Wishart distribution. Consider a set of symmetric matrixes in such a way that the diagonal element $m_{11}$ has a distribution $\exp(-m_{11}^2/4)$. In other words, the probability that this diagonal element shall assume the value $m_{11}$ is proportional to $\exp(-m_{11}^2/4)$. Then as I mentioned, and this was shown a long time ago by Wishart, the probability for the characteristic roots to be $\lambda_1, \lambda_2, \lambda_3, \ldots, \lambda_n$, if this is an $n$ dimensional matrix, is given by the expression: $$\exp(-1/2(\lambda_1^2+\lambda_2^2+..+\lambda_n^2))[(\lambda_1-\lambda_2)(\lambda_1-\lambda_3).......(\lambda_{n-1}-\lambda_n)].$$ You see again this characteristic factor which shows that the probability of two roots coinciding is 0. If you want to calculate from this formula, the probability that two successive roots have a distance X, then you have to integrate over all of them except two. This is very easy to do for the first integration, possible to do for the second integration, but when you get to the third, fourth and fifth, etc., integrations you have the same problem as in statistical mechanics, and presumably the solution of the problem will be accomplished by one of the methods of statistical mechanics. Let me only mention that I did integrate over all of them except one, and the result is $\frac{1}{2\pi}\sqrt{4n-\lambda^2}$. This is the probability that the root shall be $\lambda$. All I have to do is to integrate over one less variable than I have integrated over, but this I have not been able to do so far.

Discussion

W. HAVENS: Where does one find out about a Wishart distribution?

E. WIGNER: A Wishart distribution is given in S.S. Wilks book about statistics and I found it just by accident.





Eugene Wigner and Edward Teller

Eugene Wigner and Edward Teller – Two Hungarian-born American theoretical physicists.

Note. Edward Teller is among other things credited as being the father of the US H-bomb. He is also one of the authors of the the famous 1953 paper entitled Equation of State Calculations by Fast Computing Machines, together with Nicholas Metropolis, Arianna Rosenbluth, Marshall Rosenbluth, and Augusta Teller, which introduced the so-called Metropolis-Hastings algorithm. Eugene Wigner received a Nobel Prize in Physics in 1963 “for his contributions to the theory of the atomic nucleus and the elementary particles, particularly through the discovery and application of fundamental symmetry principles”. Wigner is often considered as a hidden genius, in comparison with Einstein.

Share

Random walk, Dirichlet problem, and Gaussian free field

September 16th, 2014 No comments
Solution of a Dirichlet problem obtained with a Monte Carlo simulation, using the Julia programming language

Solution of a Dirichlet problem by Monte Carlo simulation of probabilistic formulation, using Julia.

This post is about the discrete Dirichlet problem and Gaussian free field, linked with the random walk on \( {\mathbb{Z}^d} \). Discreteness allows to go to the concepts with minimal abstraction. The Gaussian free field (GFF) is an important Gaussian object which appears, like most Gaussian objects, as a limiting object in many models of Statistical Physics.

Symmetric Nearest Neighbors random walk. The symmetric nearest neighbors random walk on \( {\mathbb{Z}^d} \) is the sequence of random variables \( {X={(X_n)}_{n\geq0}} \) defined by the linear recursion

\[ X_{n+1}=X_n+\xi_{n+1}=X_0+\xi_1+\cdots+\xi_{n+1} \]

where \( {{(\xi)}_{n\geq1}} \) is a sequence of independent and identically distributed random variables on \( {\mathbb{Z}^d} \), independent of \( {X_0} \), and uniformly distributed on the discrete \( {\ell^1} \) sphere: \( {\{\pm e_1,\ldots,\pm e_d\}} \) where \( {e_1,\ldots,e_d} \) is the canonical basis of \( {\mathbb{R}^d} \). The term symmetric comes from the fact that in each of the \( {d} \) dimensions, both directions are equally probable in the law of the increments.

The sequence \( {X} \) is a homogeneous Markov chain with state space \( {\mathbb{Z}^d} \) since

\[ \begin{array}{rcl} \mathbb{P}(X_{n+1}=x_{n+1}\,|\,X_n=x_n,\ldots,X_0=x_0) &=&\mathbb{P}(X_{n+1}=x_{n+1}\,|\,X_n=x_n)\\ &=&\mathbb{P}(X_1=x_{n+1}\,|\,X_0=x_n)\\ &=&\mathbb{P}(\xi_1=x_{n+1}-x_n). \end{array} \]

Its transition kernel \( {P:\mathbb{Z}^d\times\mathbb{Z}^d\rightarrow[0,1]} \) is given for every \( {x,y\in\mathbb{Z}^d} \) by

\[ P(x,y) = \mathbb{P}(X_{n+1}=y\,|\,X_n=x) =\frac{\mathbf{1}_{\{\left|x-y\right|_1=1\}}}{2d} \quad\mbox{where}\quad \left|x-y\right|_1=\sum_{k=1}^d\left|x_k-y_k\right|. \]

It is an infinite Markov transition matrix. It acts on a bounded function \( {f:\mathbb{Z}^d\rightarrow\mathbb{R}} \) as

\[ (Pf)(x)=\sum_{y\in\mathbb{Z}^d}P(x,y)f(y)=\mathbb{E}(f(X_1)\,|\,X_0=x). \]

The sequence \( {X} \) is also a martingale for the filtration \( {{(\mathcal{F}_n)}_{n\geq0}} \) defined by \( {\mathcal{F}_0=\sigma(X_0)} \) and \( {\mathcal{F}_{n+1}=\sigma(X_0,\xi_1,\ldots,\xi_{n+1})} \). Indeed, by measurability and independence,

\[ \mathbb{E}(X_{n+1}\,|\,\mathcal{F}_n) =X_n+\mathbb{E}(\xi_{n+1}\,|\,\mathcal{F}_n) =X_n+\mathbb{E}(\xi_{n+1}) =X_n. \]

Dirichlet problem. For any bounded function \( {f:\mathbb{Z}^d\rightarrow\mathbb{R}} \) and any \( {x\in\mathbb{Z}^d} \),

\[ \mathbb{E}(f(X_{n+1})\,|\,X_n=x)-f(x) =(Pf)(x)-f(x) =(\Delta f)(x) \quad\mbox{where}\quad \Delta=P-I. \]

Here \( {I} \) is the identity operator \( {I(x,y)=\mathbf{1}_{\{x=y\}}} \). The operator

\[ \Delta =P-I \]

is the generator of the symmetric nearest neighbors random walk. It is a discrete Laplace operator, which computes the difference between the value at a point and the mean on its neighbors for the \( {\ell^1} \) distance:

\[ (\Delta f)(x) =\left\{\frac{1}{2d}\sum_{y:\left|y-x\right|_1=1}f(y)\right\}-f(x) =\frac{1}{2d}\sum_{y:\left|y-x\right|_1=1}(f(y)-f(x)). \]

We say that \( {f} \) is harmonic on \( {A\subset\mathbb{Z}^d} \) when \( {\Delta f=0} \) on \( {A} \), which means that on every point of \( {A} \), the value of \( {f} \) is equal to the mean of the values of \( {f} \) on the \( {2d} \) neighbors of \( {x} \). The operator \( {\Delta} \) is local in the sense that \( {(\Delta f)(x)} \) depends only on the value of \( {f} \) at \( {x} \) and its nearest neighbors. Consequently, the value of \( {\Delta f} \) on \( {A} \) depends only on the values of \( {f} \) on

\[ \bar{A}:=A\cup\partial\!A \]

where

\[ \partial\!A:=\{y\not\in A:\exists x\in A,\left|x-y\right|_1=1\} \]

is the exterior boundary of \( {A} \). In this context, the Dirichlet problem consists in finding a function which is harmonic on \( {A} \) and for which the value on \( {\partial\!A} \) is prescribed. This problem is actually a linear algebra problem for which the result below provides a probabilistic expression of the solution, based on the stopping time

\[ \tau_{\partial\!A}:=\inf\{n\geq0:X_n\in\partial\!A\}. \]

In Physics, the quantity \( {f(x)} \) models typically the temperature at location \( {x} \), while the harmonicity of \( {f} \) on \( {A} \) and the boundary condition on \( {\partial\!A} \) express the thermal equilibrium and a thermostatic boundary, respectively.

Theorem 1 (Dirichlet problem) Let \( {\varnothing\neq A\subset\mathbb{Z}^d} \) be finite. Then for any \( {x\in A} \),

\[ \mathbb{P}_x(\tau_{\partial\!A}<\infty)=1. \]

Moreover, for any \( {g:\partial\!A\rightarrow\mathbb{R}} \), the function \( {f:\bar{A}\rightarrow\mathbb{R}} \) defined for any \( {x\in\bar{A}} \) by

\[ f(x)=\mathbb{E}_x(g(X_{\tau_{\partial\!A}})) \]

is the unique solution of the system

\[ \left\{ \begin{array}{rl} f=g &\mbox{on } \partial\!A,\\ \Delta f=0&\mbox{on } A. \end{array} \right. \]

When \( {d=1} \) we recover the function which appears in the gambler ruin problem. Recall that the image of a Markov chain by a function which is harmonic for the generator of the chain is a martingale (discrete Itô formula !), and this explains a posteriori the probabilistic formula for the solution of the Dirichlet problem, thanks to the Doob optional stopping theorem.

The quantity \( {f(x)=\mathbb{E}_x(g(\tau_{\partial\!A}))=\sum_{y\in\partial\!A}g(y)\mathbb{P}_x(\tau_{\partial\!A}=y)} \) is the mean of \( {g} \) for the law \( {\mu_x} \) on \( {\partial\!A} \) called the harmonic measure defined for any \( {y\in\partial\!A} \) by

\[ \mu_x(y):=\mathbb{P}_x(X_{\tau_{\partial\!A}}=y) \]

Proof: The property \( {\mathbb{P}_x(\tau_{\partial\!A}<\infty)=1} \) follows from the Central Limit Theorem or by using conditioning which gives a geometric upper bound for the tail of \( {\tau_{\partial\!A}} \).

Let us check that the proposed function \( {f} \) is a solution. For any \( {x\in\partial\!A} \), we have \( {\tau_{\partial\!A}=0} \) on \( {\{X_0=x\}} \) and thus \( {f=g} \) on \( {\partial\!A} \). Let us show now that \( {\Delta f=0} \) on \( {A} \). We first reduce the problem by linearity to the case \( {g=\mathbf{1}_{\{z\}}} \) with \( {z\in\partial\!A} \). Next, we write, for any \( {y\in\bar{A}} \),

\[ \begin{array}{rcl} f(y) &=&\mathbb{P}_y(X_{\tau_{\partial\!A}}=z)\\ &=&\sum_{n=0}^\infty\mathbb{P}_y(X_n=z,\tau_{\partial\!A}=n)\\ &=&\mathbf{1}_{y=z}+\mathbf{1}_{y\in A}\sum_{n=1}^\infty\sum_{x_1,\ldots,x_{n-1}\in A}P(y,x_1)P(x_1,x_2)\cdots P(x_{n-1},z). \end{array} \]

On the other hand, since \( {f=0} \) on \( {\partial\!A\setminus\{z\}} \) and since \( {\Delta} \) is local, we have, for any \( {x\in A} \),

\[ (P f)(x) =\sum_{y\in\mathbb{Z}^d}P(x,y)f(y) =P(x,z)f(z)+\sum_{y\in A}P(x,y)f(y). \]

As a consequence, for any \( {x\in A} \),

\[ \begin{array}{rcl} (P f)(x) &=&P(x,z)f(z)+\sum_{n=1}^\infty\sum_{y,x_1,\ldots,x_{n-1}\in A} P(x,y)P(y,x_1)\cdots P(x_{n-1},z)\\ &=&P(x,z)f(z)+(f(x)-(\mathbf{1}_{x=z}+P(x,z))), \end{array} \]

which is equal to \( {f(x)} \) since \( {\mathbf{1}_{x=z}=0} \) and \( {f(z)=1} \). Hence \( {Pf=f} \) on \( {A} \), in other words \( {\Delta f=0} \) on \( {A} \).

To establish the uniqueness of the solution, we first reduce the problem by linearity to show that \( {f=0} \) is the unique solution when \( {g=0} \). Next, if \( {f:\bar{A}\rightarrow\mathbb{R}} \) is harmonic on \( {A} \), the interpretation of \( {\Delta f(x)} \) as a difference with the mean on the nearest neighbors allows to show that both the minimum and the maximum of \( {f} \) on \( {\bar{A}} \) are (at least) necessarily achieved on the boundary \( {\partial\!A} \). But since \( {f} \) is vanishes on \( {\partial\!A} \), it follows that \( {f} \) vanishes on \( {\bar{A}} \). ☐

Dirichlet problem and Green function. Here is a generalization of Theorem 1. When \( {h=0} \) we recover Theorem 1.

Theorem 2 (Dirichlet problem and Green function) If \( {\varnothing\neq A\subset\mathbb{Z}^d} \) is finite then for any \( {g:\partial\!A\rightarrow\mathbb{R}} \) and \( {h:A\rightarrow\mathbb{R}} \), the function \( {f:\bar{A}\rightarrow\mathbb{R}} \) defined for any \( {x\in\bar{A}} \) by

\[ f(x)=\mathbb{E}_x\left(g(X_{\tau_{\partial\!A}})+\sum_{n=0}^{\tau_{\partial\!A}-1}h(X_n)\right) \]

is the unique solution of

\[ \left\{ \begin{array}{rl} f=g&\mbox{on } \partial\!A,\\ \Delta f=-h&\mbox{on } A. \end{array} \right. \]

When \( {d=1} \) and \( {h=1} \) then we recover a function which appears in the analysis of the gambler ruin problem.

For any \( {x\in A} \) we have

\[ f(x) =\sum_{y\in\partial\!A}g(y)\mathbb{P}_x(\tau_{\partial\!A}=y)+\sum_{y\in A}h(y)G_A(x,y) \]

where \( {G_A(x,y)} \) is the average number of passages at \( {y} \) starting from \( {x} \) and before escaping from \( {A} \):

\[ G_A(x,y):=\mathbb{E}_x\left\{\sum_{n=0}^{\tau_{\partial\!A}-1}\mathbf{1}_{X_n=y}\right\} =\sum_{n=0}^\infty\mathbb{P}_x(X_n=y,n<\tau_{\partial\!A}). \]

We say that \( {G_A} \) is the Green function of the symmetric nearest neighbors random walk on \( {A} \) killed at the boundary \( {\partial\!A} \). It is the inverse of the restriction \( {-\Delta_A} \) of \( {-\Delta} \) to functions on \( {\bar{A}} \) vanishing on \( {\partial\!A} \):

\[ G_A=-\Delta_A^{-1}. \]

Indeed, when \( {g=0} \) and \( {h=\mathbf{1}_{\{y\}}} \) we get \( {f(x)=G_A(x,y)} \) and thus \( {\Delta_AG_A=-I_A} \).

Proof: Thanks to Theorem 1 it suffices by linearity to check that \( {f(x)=\mathbf{1}_{x\in A}G_A(x,z)} \) is a solution when \( {g=0} \) and \( {h=\mathbf{1}_{\{z\}}} \) with \( {z\in A} \). Now for any \( {x\in A} \),

\[ \begin{array}{rcl} f(x) &=&\mathbf{1}_{\{x=z\}}+\sum_{n=1}^\infty\mathbb{P}_x(X_n=z,n<\tau_{\partial\!A})\\ &=&\mathbf{1}_{\{x=z\}}+\sum_{y:\left|x-y\right|_1=1}\sum_{n=1}^\infty\mathbb{P}(X_n=z,n<\tau_{\partial\!A}\,|\,X_1=y)P(x,y)\\ &=&\mathbf{1}_{\{x=z\}}+\sum_{u:\left|x-y\right|_1=1}f(y)P(x,y) \end{array} \]

thanks to the Markov property. We have \( {f=h+Pf} \) on \( {A} \), in other words \( {\Delta f=-h} \) on \( {A} \). ☐

Beyond the symmetric nearest neighbors random walk. The proofs of Theorem 1 and Theorem 2 remain valid for asymmetric nearest neighbors random walks on \( {\mathbb{Z}^d} \), provided that we replace the generator \( {\Delta} \) of the symmetric nearest neighbors random walk by the generator \( {L:=P-I} \), which is still a local operator: \( {\left|x-y\right|>1\Rightarrow L(x,y)=P(x,y)=0} \). One may even go beyond this framework by adapting the notion of boundary: \( {\{y\not\in A:\exists x\in A, L(x,y)>0\}} \).

Gaussian free field. The Gaussian free field is model of Gaussian random interface for which the covariance matrix is the Green function of the discrete Laplace operator. More precisely, let \( {\varnothing\neq A\subset\mathbb{Z}^d} \) be a finite set. An interface is a height function \( {f:\bar{A}\rightarrow\mathbb{R}} \) which associates to each site \( {x\in\bar{A}} \) a height \( {f(x)} \), also called spin in the context of Statistical Physics. For simplicity, we impose a zero boundary condition: \( {f=0} \) on the boundary \( {\partial\!A} \) of \( {A} \).

Let \( {\mathcal{F}_A} \) be the set of interfaces \( {f} \) on \( {\bar{A}} \) vanishing at the boundary \( {\partial\!A} \), which can be identified with \( {\mathbb{R}^A} \). The energy \( {H_A(f)} \) of the interface \( {f\in\mathcal{F}_A} \) is defined by

\[ H_A(f)=\frac{1}{4d}\sum_{\substack{\{x,y\}\subset\bar{A}\\\left|x-y\right|_1=1}}(f(x)-f(y))^2, \]

where \( {f=0} \) on \( {\partial\!A} \). The flatter is the interface, the smaller is the energy \( {H_A(f)} \). Denoting \( {\left<u,v\right>_A:=\sum_{x\in A}u(x)v(x)} \), we get, for any \( {f\in\mathcal{F}_A} \),

\[ H_A(f) =\frac{1}{4d}\sum_{x\in A}\sum_{\substack{y\in\bar{A}\\\left|x-y\right|_1=1}}(f(x)-f(y))f(x) =\frac{1}{2}\left<-\Delta f,f\right>_A. \]

Since \( {H_A(0)=0} \) and \( {H_A(f)=0} \) give \( {f=0} \), the quadratic form \( {H_A} \) is not singular and we can define the Gaussian law \( {Q_A} \) on \( {\mathcal{F}_A} \) which favors low energies:

\[ Q_A(df)=\frac{1}{Z_A}e^{-H_A(f)}\,df \quad\mbox{where}\quad Z_A:=\int_{\mathcal{F}_A}\!e^{-H_A(f)}\,df. \]

This Gaussian law, called the Gaussian free field, is characterized by its mean \( {m_A:A\rightarrow\mathbb{R}} \) and its covariance matrix \( {C_A:A\times A\rightarrow\mathbb{R}} \), given for any \( {x,y\in A} \) by

\[ m_A(x):=\int\!f_x\,Q_A(df)=0 \]

and

\[ C_A(x,y):=\int\!f_xf_y\,Q_A(df)-m_A(x)m_A(y)=-\Delta_A^{-1}(x,y)=G_A(x,y), \]

where \( {f_x} \) denotes the coordinate map \( {f_x:f\in\mathcal{F}_A\mapsto f(x)\in\mathbb{R}} \).

Simulation of the Gaussian free field. The simulation of the Gaussian free field can be done provided that we know how to compute a square root of \( {G_A} \) in the sense of quadratic forms, using for instance a Cholesky factorization or diagonalization. Let us consider the square case:

\[ A=L(0,1)^d\cap\mathbb{Z}^d=\{1,\ldots,L-1\}^d. \]

This gives \( {\bar{A}=\{0,1,\ldots,L\}^d} \). In this case, one can compute the eigenvectors and eigenvalues of \( {\Delta_A} \) and deduce the ones of \( {G_A=-\Delta_A^{-1}} \). In fact, the continuous Laplace operator \( {\Delta} \) on \( {[0,1]^d\in\mathbb{R}^n} \), with Dirichlet boundary conditions, when defined on the Sobolev space \( {\mathrm{H}_0^2([0,1]^d)} \), is a symmetric operator with eigenvectors \( {\{e_n:n\in\{1,2,\ldots\}^d\}} \) and eigenvalues \( {\{\lambda_n:n\in\{1,2,\ldots\}^d\}} \) given by

\[ e_n(t):=2^{d/2}\prod_{i=1}^d\sin(\pi n_i t_i), \quad\mbox{and}\quad \lambda_n:=-\pi^2\left|n\right|_2^2 =-\pi^2(n_1^2+\cdots+n_d^2). \]

Similarly, the discrete Laplace operator \( {\Delta_A} \) with Dirichlet boundary conditions on this \( {A} \) has eigenvectors \( {\{e^L_n:n\in A\}} \) and eigenvalues \( {\{\lambda_n^L:n\in A\}} \) given for any \( {k\in A} \) by

\[ e^L_n(k):=e_n\left(\frac{k}{L}\right) \quad\mbox{and}\quad \lambda_n^L:=-2\,\sum_{i=1}^d \sin^2\left(\frac{\pi n_i}{2L}\right). \]

The vectors \( {e_n^L} \) vanish on the boundary \( {\partial\!A} \). It follows that for any \( {x,y\in A} \),

\[ \Delta_A(x,y)=\sum_{n\in A}\lambda_n^L\left<e^L_n,f_x\right>\left<e^L_n,f_y\right> =\sum_{n\in A}\lambda_n^L e^L_n(x)e^L_n(y) \]

and

\[ G_A(x,y)=-\sum_{n\in A}\left(\lambda_n^L\right)^{-1} e^L_n(x)e^L_n(y). \]

A possible matrix square root \( {\sqrt{G_A}} \) of \( {G_A} \) is given for any \( {x,y\in A} \) by

\[ \sqrt{G_A}(x,y)=-\sum_{n\in A}\left(\lambda_n^L\right)^{-1/2} e^L_n(x)e^L_n(y). \]

Now if \( {Z={(Z_y)}_{y\in A}} \) are independent and identically distributed Gaussian random variables with zero mean and unit variance, seen as a random vector of \( {\mathbb{R}^A} \), then the random vector

\[ \sqrt{G_A}Z = \left(\sum_{y\in A}\sqrt{G_A}(x,y)Z_y\right)_{x\in A} =\left(\sum_{y\in A}\sum_{n\in A}\left(-\lambda_n^L\right)^{-1/2}e_n^L(x)e_n^L(y)Z_y\right)_{x\in A} \]

is distributed according to the Gaussian free field \( {Q_A} \).

Continuous analogue. The scaling limit \( {\varepsilon\mathbb{Z}^d\rightarrow\mathbb{R}^d} \) leads to natural continuous objects (in time and space): the simple random walk becomes the standard Brownian Motion via the Central Limit Theorem, the discrete Laplace operator becomes the Laplace second order differential operator via a Taylor formula, while the discrete Gaussian free field becomes the continuous Gaussian free field (its covariance is the Green function of the Laplace operator). The continuous object are less elementary since their require much more analytic and probabilistic machinery, but in the mean time, they provide differential calculus, a tool which is problematic in discrete settings due in particular to the lack of chain rule.

Further reading.

Note. The probabilistic approach to the Dirichlet problem goes back at least to Shizuo Kakutani (1911 – 2004), who studied around 1944 the continuous version with Brownian Motion. This post is the English translation of an excerpt from a forthcoming book on stochastic models, written, in French, together with my old friend Florent Malrieu.

1D GFF simulated with Julia

1D GFF simulated with Julia

2D GFF simulated with Julia

2D GFF simulated with Julia

Johann Peter Gustav Lejeune Dirichlet (1805 - 1859) who probably never thought about random walks

Johann Peter Gustav Lejeune Dirichlet (1805 – 1859) who probably never thought about random walks and Gaussian fields

#
# load within julia using include("dirichlet.jl")
#
nx, ny = 25, 25
f = zeros(nx,ny)
f[1,:], f[nx,:], f[:,1], f[:,ny] = 2, 2, -2, -2
C = zeros(nx,ny)
N = 5000
#
for x = 1:nx
 for y = 1:ny
  for k = 1:N
   xx = x
   yy = y
   while ((xx > 1) && (xx < nx) && (yy > 1) && (yy < ny))
    b = rand(2)
    if (b[1] < .5)
     if (b[2] < .5)
      xx -= 1
     else
      xx += 1
     end
    elseif (b[2] < .5)
     yy -= 1
    else
     yy += 1
    end
   end # while
   C[x,y] += f[xx,yy]
  end # for k
 end # for y
end # for x
using Compose, Gadfly
draw(PNG("dirichlet.png", 10cm, 10cm), spy(C/N))
#
# load within julia using include("gff.jl")
#
Pkg.add("Gadfly") # produces "INFO: Nothing to be done." if already installed.
Pkg.add("Cairo") # idem.
#Pkg.add("PyPlot") # idem.
using Compose, Gadfly, Cairo # for 2D graphics
#using PyPlot # for 3D graphics (Gadfly does not provide 3D graphics)
#
# dimension 1
#
L = 500
Z = randn(L-1)
lambda = 2*sin(pi*[1:L-1]/(2*L)).^2
evec = sqrt(2)*sin(pi*kron([1:L-1],[1:L-1]')/L)
GFF1 = zeros(L-1)
for x = 1:L-1
    for y = 1:L-1
        for n = 1:L-1
            GFF1[x] += (lambda[n])^(-1/2)*evec[n,x]*evec[n,y]*Z[y]
        end
    end
end
# graphics ith Gadfly
p = plot(x = [1:L-1], y = GFF1,
         Geom.line,
         Guide.xlabel(""),
         Guide.ylabel(""),
         #Guide.title("GFF"),
         Theme(default_color=color("black")))
draw(PNG("gff1.png", 10cm, 10cm), p)
#
# dimension 2
#
L = 20
Z = randn(L-1,L-1)
AUX = kron(ones(L-1)',[1:L-1])
lambda = 2*sin(pi*AUX/(2*L)).^2 + 2*sin(pi*AUX'/(2*L)).^2
evec = zeros(L-1,L-1,L-1,L-1) # n1,n2,k1,k2 : e_n^L(k)
for n1 = 1:L-1
 for n2 = 1:L-1
  AUX = kron(ones(L-1)',[1:L-1])
  evec[n1,n2,:,:] = reshape(2*sin(pi*n1*AUX/L).*sin(pi*n2*AUX'/L),(1,1,L-1,L-1))
 end
end
GFF2 = zeros(L-1,L-1)
for x1 = 1:L-1
 for x2 = 1:L-1
  for y1 = 1:L-1
   for y2 = 1:L-1
    for n1 = 1:L-1
     for n2 = 1:L-1
      aux = (lambda[n1,n2])^(-1/2)
      aux *= evec[n1,n2,x1,x2]
      aux *= evec[n1,n2,y1,y2]
      aux *= Z[y1,y2]
      GFF2[x1,x2] += aux
     end
    end
   end
  end
 end
end
# graphics with PyPlot
#surf(GFF2)
#savefig("gff2.svg")
# graphics with Gadfly
draw(PNG("gff2.png", 10cm, 10cm), spy(GFF2))
Share
